FEATURES
1. Industrial grade LCD panel, wide viewing angle, high nits, true color.
2. Option for resistive or capacitive type touch screen, high sensitive and fast response.
3. High performance motherboard, 7x24 continuous operation.
4. Support wall mounting,desk stand mouting etc.
5. 1000-1500 nits sunlight readable optional.
6. Customized integrated metal housing, good mechanical properties, excellent heat dissipation.
7. Wide temperature range: operating: -20 to 70°C, storage: -30 to 80°C.
8. VGA,HDMI,DVI input.
9. External 100/240 auto-switch AC power adapter.
SPECIFICATION
LCD Panel | |
Panel size | 18.5” |
Native resolution | 1366*768 |
Aspect ratio | 4:3 |
Active Area(mm) | 409.8(H) x 230.4(V) |
Brightness | 1000nits-1200nits |
LED Life Time | ≥50K hours |
Contrast Ratio (Center of screen) | 500:1 |
Response Time | 5ms |
Viewing angle | 85°/85°/80°/80° (R/L/U/D) |
Support Color | 16.7M colors |
Touch | |
Touchscreen type | Project Capacitive Touch (10 points) |
Surface Hardness | 3H |
Luminousness | 90% |
Touch interface | USB (RS232 optional) |
Touch response time | 2ms |
Working Life | >50 million times |
Touch options | (5 wires restive touch,IR touch optional) |
Signal Ports | |
VGA | 1×VGA |
DVI | 1×DVI |
HDMI | 1×HDMI |
Audio in/out,DP | optional |
OSD | |
OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc. |
Support OS | Windows XP , Windows /7/8/10 ,Linux, Mac OS X,Android ect. |
Power Supply | |
External Power Supply | AC 100 - 240V , 50-60Hz |
Working voltage | DC 12V |
Power consumption | ≤10W |
Enclosure | |
Material | High strength cold rolled steel back case |
Color/Dimension | Black, white, Silver , color and dimensions are can be customized |
VESA mounting | 75×75mm/100×100mm |
IP grade | No IP rating |
Operating Environment | |
Temperature Range | operating: -20 to 70°C, storage: -30 to 80°C |
Relative humidity | operating: 10% to 80% , storage :5% to 90% |
Packing Details | |
Net weight | 6.8kg(Approx.) |
Gross weight | 7.8kg(Approx.) |
Accessories | Power adapter, power cord, USB touch cable, HDMI/ VGA cable, embedded screws |
Other | |
Mounting | VESA mounting |
wall mounting brackets (optional) | |
desk stand holder (optional) | |
Warranty | 1 year warranty |
Certificates | CE, FCC, RoHS |
Order Information | |
18.5 inch sunlight readable high brightness LCD monitor no touch/ADV185CMNTHB01 | |
18.5 inch sunlight readable high brightness LCD monitor with tempered glass /ADV185CMTGHB01 | |
18.5 inch sunlight readable high brightness LCD monitor with resistive touch/ADV185CMRTHB01 | |
18.5 inch sunlight readable high brightness LCD monitor with capacitive touch/ADV185CMFCTHB01 | |
18.5 inch sunlight readable high brightness LCD monitor with IR touch/ADV185CMITHB01 |
