10.1 INCH WIDE TEMPERATURE 1000 NITS EMBEDDED MONITOR

10.1 INCH WIDE TEMPERATURE 1000 NITS EMBEDDED MONITOR

Panel size：10.1"
Resolution：1280*800
Surface Treatment：Anti glare
Interface：HDMI/DVI/VGA
Brightness：1000nits
Touch Type：Capacitive
IP grade：Front IP65

FEATURES

1. Front bezel aluminum alloy brushed metal craft, seamless design, front IP65 waterproof and dustproof.

2. Industrial LCD panel, wide viewing angle, high nits, true color.

3. Adopt multi-points PCAP touch panel, high sensitive and fast-response. Covered with 2mm tempered glass for vandalproof.

4. EETI waterproof solution, touch function can work well with drop water on the screen.

5.1000 nits, sunlight readable, with light sensor for auto dimming.

6. Anti glare.

7. High performance mainboard, 7x24 continuous operation.

8. Wide temperature range: operating: -20 to 70°C, storage: -30 to 80°C.

9. Support wall mounting, embedded mounting, desk stand mounting etc.

SPECIFICATION

LCD Panel
Panel size
Native resolution	1920*1080
Aspect ratio	16:9
Brightness	250 nits
LED Life Time	≥50K hours
Contrast Ratio (Center of screen)	1000:1
Response Time	3s
Viewing angle	80°/80°/80°/80° (R/L/U/D)
Support Color	16.7M colors
Touch
Touchscreen type	Project Capacitive Touch (10 points)
Surface Hardness	3H
Luminousness	90%
Touch interface	USB (RS232 optional)
Touch response time	2ms
Working Life	>50 million times
Touch options	(5 wires restive touch, IR touch optional)
Signal Ports
VGA	1×VGA
DVI	1×DVI
HDMI	1×HDMI
Audio in/out	optional
OSD
OSD control	Brightness, contrast ratio, auto adjustment, H/V position, language select etc.
Support languages	English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc.
Support OS	Windows XP , Windows /7/8/10 ,Linux, Mac OS X,Android ect.
Power Supply
External Power Supply	AC 100 - 240V , 50-60Hz
Working voltage	DC 12V
Power consumption	≤25W
Enclosure
Material	aluminium alloy bezel+High strength cold rolled steel back case
Color	Black, white, Silver , color can be customized
VESA mounting	75×75mm/100×100mm
IP grade	Front panel IP65 waterproof
Operating Environment
Temperature Range	operating: -20 to 70°C, storage: -30 to 80°C
Relative humidity	operating: 10% to 80% , storage :5% to 90%
Packing Details
Net weight	1.7kg
Gross weight	2.8kg
Product Dimension	29.95×21×3.3cm
Packing size	33×30×10cm
Accessories	Power adapter, power cord, USB touch cable, HDMI/ VGA cable, embedded screws
Other
mounting	embedded mounting
	wall mounting brackets (optional)
	desk stand holder (optional)
Warranty	1 year warranty
Certificates	CE, FCC, RoHS
